Keencut Simplex Entry Level Cutter Bar – 1100mm
Key Features
Keencut Simplex is the perfect entry-level cutter bar for your workshop. Its innovative design offers a straightness guarantee of 1mm, or 1:3000, over the length of the cutter bar, making it a cost-effective investment which delivers a high degree of accuracy when cutting media up to 3.1m in width.
- Quick and easy to use
- Cuts to a depth of 10mm
- Uses standard utility knife blades
- Cuts a wide range of flexible and rigid materials
- Five-year product guarantee
£352.00 + VAT
Keencut Simplex Dimensional Chart
| SIM110 | SIM160 | SIM210 | SIM260 | SIM310 | |
|---|---|---|---|---|---|
| Cut Length cm (”) | 110cm (44") | 160 (64") | 210 (84") | 260 (104") | 310 (124") |
| A cm (”) | 127(50") | 177(70.5") | 227(89.5") | 277(89.5") | 327(128.75") |
| B cm (”) | 11(4.4") | 11(4.4") | 11(4.4") | 11(4.4") | 11(4.4") |
Download the Keencut Simplex manual
Keencut Simplex benefits
Lightweight yet hardwearing construction
- Lightweight construction for convenient portability even over longer lengths
- High tensile aerospace aluminium alloy
- Super grade anodising for lifetime good looks and function
Ergonomic Cutting Head
- Original Keencut 'Rocker Style' Cutting Head
- Accepts standard off-the-shelf Medium Duty Utility Blades
- Fitted with Blade Depth Guide and Blade Ejector
- Spring loaded cutting head so blade instantly retracts when not in use
- Patented space age bearing and slide system designed for operator adjustment and minimal maintenance
Textile Cutter - Optional
- Comes Complete with Circular Knife Blade
- 10 pack of replacement blades available, product code TEXB
- Cold cut textiles and other delicate materials
- Ideal for trimming thin strips off banners and posters where a knife blade would be too aggressive
- Comes fitted with Red Blade Guard to be engaged when not in use for optimum safety
- Order On-line
Keencut Simplex’s innovative design offers
- Exact accuracy for general purpose cutting of wide format materials up to 3.1mtrs wide.
- Keencut Simplex features a straightness guarantee of 1.00mm, or 1:3000 over the length of the cutter bar, Simplex is an economical alternative to the Keencut Javelin where less extreme accuracy is required.
Talk To Our Specialist team
SIMPLICITY IMPLIED
- Safe
- Accurate
- Portable
- Affordable
An economic solution for all your multi-purpose cutting needs.
Keencut Simplex blades
The Simplex uses utility knife blades and features blade depth adjustment and a spring-loaded blade. The utility blades will cut to a depth of 10mm (0.4”). The patented linear bearings have been tested under load for 1600km (1000 miles) and carry a 20 year guarantee. Full length silicon rubber grip strips ensure all work is clamped when cutting and also protect the surface of the material being cut.
What will it cut?
PVC foam board
Correx
Foam Centred Board
MDF
Aluminium Composite
Cast Acrylic
Extruded Polystyrene
